The Telwin Electromig 300 Synergic is a multi-process welding machine with inverter technology, supporting MIG/MAG, flux, brazing, MMA, and TIG DC-Lift with microprocessor control and a 4-roller wire feed system. It offers flexible use across welded materials (steel, stainless steel, aluminium) and braze-welded materials (galvanised sheets), suiting a wide range of applications in industry, maintenance, installation, and bodywork.
Synergistic settings make the unit straightforward to operate, while Telwin's ATC technology uses advanced arc control to achieve excellent welding results on thin-walled materials with ease. The unit offers manual and synergic operation with 30 preset synergy curves, adjustable MIG/MAG settings including wire speed start ramp, electronic reactance, burn-back time, and post-gas duration, plus 2/4-stroke and spot operation with material thickness selectable in inches or mm.
Key Features
- Multi-process welder: MIG/MAG, flux, brazing, MMA, TIG DC-Lift
- Microprocessor control with 4-roller wire feed system
- Manual and synergic operation, 30 preset synergy curves
- Telwin ATC technology for advanced arc control on thin-walled materials
- Adjustable wire feed start ramp, electronic reactance, burn-back time, post-gas duration
- 2/4-stroke and spot operation, material thickness selectable in inches or mm
- Thermostat, overvoltage, undervoltage, overcurrent, and motor/generator protection (+/-15%)
Included with Delivery
- 1x MT25 MIG torch (742183)
- 1x earth cable (713192)
- 1x torch hook (645704)
- 1x wire feed roller, 4R 0.6FE-0.8/0.9FE "P-K" (742576)
Process Specifications
| Process | Wire/Electrode Detail |
|---|---|
| Steel wire | Ø 0.6 - 1.2 mm (max. 15kg spool) |
| Stainless steel wire | Ø 0.8 - 1.2 mm (max. 15kg spool) |
| Aluminium wire | Ø 0.8 - 1.2 mm (max. 15kg spool) |
| Flux-cored wire | Ø 0.8 - 1.2 mm (max. 15kg spool) |
| Solder wire | Ø 0.8 - 1.2 mm (max. 15kg spool) |
| Electrodes | Ø 1.6 - 6.0 mm |
Specifications
| Specification | Detail |
|---|---|
| Type | Multi-Process Inverter Welder (MIG/MAG, Flux, Brazing, MMA, TIG) |
| Dimensions (L x W x H) | 280 x 880 x 800 mm |
| Control range | 20 - 300 A |
| Current | 270 A (30%) |
| Current requirement | 10 - 15 A |
| Max power consumption | 6.5 - 9 kW |
| Voltage/Frequency | 400 V, 50/60 Hz |
| Open circuit voltage | 63 V |
| Protection class | IP23 |
| Part number | 19200304 |
| Reference number | 816270 |
| Weight | 57.50 kg |
| EAN | 3154020079250 |
| Condition | New |
