Ball Pin | 7/8" UNF, Extended Length for Farm Use Only - 20000010

Attach medium-duty farm implements and trailers with the GRANIT Extended Ball Pin (Part No. 20000010). This pin features a 7/8" diameter ball and a long 190mm shank with a 7/8 UNF thread, designed for fixed drawbar applications requiring extra clearance. Crucially, this pin is not approved for road use and is intended solely for farm, forestry, and off-road towing.

Key Features:

• Agricultural Use Only: Designed for off-road and farm towing, not for road-going trailers.

• Extended 190mm Shank: Provides additional space for implement frames or specific mounting setups.

• 7/8" Ball Diameter: Offers a strong, secure pivot point for agricultural trailer couplings and implement eyes.

• 7/8 UNF Thread: Standard coarse thread for secure mounting into drawbars.

• Heavy-Duty Construction: Built to handle the shock loads of demanding farm work.

Part Number: 20000010
Thread: 7/8 UNF
Ball Diameter (A): 22mm / 0.86" (approx. 7/8")
Key Dimensions (mm): B: 190 (Shank Length), C: 100
Use: Farm and off-road applications only.

Ideal For: Connecting medium-duty agricultural trailers, fertiliser spreaders, and towed implements to tractor drawbars where a standard ball pin is too short.

Warning: Not approved for road use. For highway towing, always use a compliant, type-approved coupling and ball.
