Rear Brake Backing Plate for TRX250 Recon, TRX 250X, and TRX250EX Sportrax, 97-Up. This precision-made plate restores proper rear drum brake alignment and helps deliver consistent stopping power after maintenance or restoration. Built to endure off-road conditions, it provides a durable mounting foundation for the brake hardware and long-lasting reliability in trail and farm use.

Unlike a bent or worn backing plate that can cause shoe misalignment, drag, or uneven braking, this aftermarket replacement tackles the root issues head-on. It offers reliable fitment and robust construction that resists mud, water, and wear, making it a dependable choice for both trail riding and agricultural duties where consistent braking matters most.

Comprehensive Vehicle Fitment

Fitment data drawn from multiple listings and retailers indicating compatibility with the TRX250 family in 1997 and newer model years.

Sources: OEM cross-reference databases and retailer product pages confirm compatibility for the TRX250 Recon, TRX250X, and TRX250EX Sportrax families dating from 1997 onward.

Product Specifications

OEM & Aftermarket Cross-Reference Information

What's Included

The box contains the essential component for rear drum brake restoration:

• Rear Brake Backing Plate

Why Choose This Aftermarket Replacement?

• Direct-Fit Compatibility: Engineered to bolt to the same mounting points as the OEM backing plate for 97-Up TRX250 models, simplifying installation.
• OEM Cross-Reference: Includes established OEM cross-references to streamline parts sourcing and reduce inventory clutter.
• Premium Materials: Constructed from robust backing plate steel designed to resist bending and fatigue in rugged off-road conditions.
• Performance Restoration: Restores precise brake shoe alignment and drum engagement for predictable stopping power.
• Cost-Effective Alternative: Provides a reliable, budget-friendly option that preserves braking performance without OEM pricing.
• Maintenance-Friendly: Simplifies future service with a straightforward replacement path when the drum brake starts to show misalignment or drag.

Installation Notes:

• Before installation, thoroughly clean the mounting surface on the rear brake drum hub and inspect for corrosion or distortion.
• Compare the new backing plate’s mounting holes to the axle/hub pattern to confirm alignment before tightening.
• Do not reinstall bent or damaged brake hardware; replace worn pins and springs only if you’re sourcing a full kit or have verified equivalents.
• Check for proper clearance between the backing plate and the brake drum as you install to prevent contact or rubbing during rotation.
• Torques: use manufacturer-recommended torque values for the backing plate bolts as you would with the OEM part; if unsure, consult service manuals or a qualified tech.
• Reassemble the brake components in the proper sequence (drum, shoes, springs, plate) and verify free spin with light hand rotation to ensure no binding.

Why Upgrade?

Running a worn or bent rear brake backing plate can lead to uneven shoe contact, braking drag, or inconsistent stopping power, especially under muddy or dusty trail conditions. This aftermarket replacement restores correct alignment and mounting integrity, revitalizing rear-brake performance and overall braking reliability for your TRX250 family machine.
